Type 33, Clamp-On Crossover

Adjustable Short Variable angle 45° - 60°. This adjustable angle clamp is used to join tubes between 45° and 60°. Use for diagonal braces, struts and an angled top rail joint to vertical posts on stairs.

Adjustable Two Socket Cross. This variable angled clamp may be used at any selected angle between 30 and 45 degrees. Type 7 can be used for the top rail.

Male Corner Lug 90°. Similar to Type 36 with two lugs which are perpendicular to each other.

Galv. Ridge Fittings 27½°. This tube fitting is used for roof construction and is usually in combination with type 85E.

Tubefitting sleeve with gradient. Connecting clamp for tubes of unequal diameter.

Angle of continuous upright - 40 mm. Corner connection (90°), where the vertical tube runs through the clamp.
