Street Workout Set no. 6

Butterfly - Outdoor Fitness

- max. free fall height: 0,41 m
- product dimensions (length x width x height) 0,83 x 0,85 x 1,81 m
- impact area dimensions: (length x width) 3,83 x 3,85 m
- free zone: 12,6 m2
- a solid steel construction made of round pipes ø60,3x2,9mm
- the seat and the back rest made of durable 15mm HDPE sheet
- an arm of the device made of ø48,3x2,9mm pipe with a handle of ø16 rod covered by an artificial material
- automatic, maintenance-free rubber stringing units provide incremental rise of resistance of gym device
- the construction possess a protection against sudden drawing back of the device arms
- all steel elements are protected against corrosion and painted with acrylic lacquer
- the device should be mounted to the Pylon of Tytan System series

Ask for an offer!

Horizontal Ladder, Outdoor Fitness.

- max. free fall height: 0,94 m
- product dimensions: (length x width x height) 2,49 x 0,61 x 1,94 m
- impact area dimensions: (length x width) 5,49 x 3,61 m
- free zone: 17,8 m2
- a solid steel construction made of round pipes ø48,3x2,9mm
- rungs of ladder made of ø38x2,6mm pipes
- all steel elements are protected against corrosion and painted with an acrylic lacquer
- the device should be mounted to the Pylon of Tytan System series

Ask for an offer!

Pull Up Bar, Outdoor Fitness

- max. free fall height: 1,05 m
- product dimensions: (length x width x height) 0,60 x 0,80 x 2,14 m
- impact area dimensions: (length x width) 3,60 x 3,80 m
- free zone 12,2 m2
- a solid steel construction made of round pipes ø60,3 x 2,9mm
- the handles made of ø38 x 2,6mm pipe
- the device intended to training arm muscles
- all steel elements are protected against corrosion and painted with an acrylic lacquer
- the device should be mounted to the Pylon of Tytan System series

Ask for an offer!

Pylon 4 - for 4 Gym Station.

- a basic module for mounting 1 or 2 gym devices of System Tytan series excluding: Pendulum, Pendulum II, Shears, Bench with Leg Curl, Exercise Bench, Back Massager, Tai Chi Discs 3, Tai Chi Discs 4, Air Walker
- a solid steel construction made of ø60,3x 2,9mm pipe and profile: 120x40x3mm,
- includes a decorative 6mm HPL board with the logo and a space for instruction on how to use
- all steel elements are protected against corrosion and painted with an acrylic lacquer
- includes a foundation made of concrete of class C25/30 which make installation easier
- product dimensions: (length x width x height) 0,55 x 0,55x 1,81 m

Ask for an offer!

Street Workout Set no. 21

- max. free fall height 2,80 m
- product dimensions: (length x width x height) 9,78 x 6,50 x 3,90 m
- impact area: (length x width) 12,78 x 10,26 m
- free zone: 96,8 m2
- all posts made of closed profiles 100x100x3mm
- bars and ladder made of ø33,7x4mm pipes
- exercise pole and push-up bars made of Ø48,3x2,9mm pipe
- horizontal ladder made of Ø33,7x4mm and Ø38x4mm pipes
- seat of the exercise bench made of 15mm HDPE sheet
- gymnastic rings made of stainless steel pipe ø30x2mm and armed rope ø16mm
- all steel elements are protected against corrosion and painted with an acrylic lacquer
- the set includes foundations made of concrete class C25/30
- all posts shall be set in concrete class C16/20

Components of the set:

- gymnastic rings – 1set
- horizontal ladder – 1pc.
- ladder – 1pc.
- exercise pole – 1pc.
- parallel bars – 1 set
- push-up bars – 1 set
- pull-up bar – 7pcs.
- exercise bench with small ladder – 1pc.

Ask for an offer!

Street Workout Set no. 11

- max. free fall height: 2,40 m
- product dimensions: (length x width x height) 8,84 x 5,38 x 3,5 m
- impact area: (length x width) 12,10 x 8,91 m
- free zone: 84,3 m2
- all posts made of closed profiles 100x100x3mm
- construction made of pipes: ø33,7x4mm, ø38x4mm and ø48,3x2,9mm
- log roll made of ø133x4mm pipe and lined with planks
- gymnastic rings made of stainless steel pipe ø30x2mm and armed rope ø16mm
- all steel elements are protected against corrosion and painted with an acrylic lacquer
- the set includes foundations made of concrete class C25/30
- all posts shall be set in concrete class C16/20

Components of the Set:

- exercise bench with small ladder – 2 pcs.
- parallel bar – 3 pcs.
- slanted bar – 1 pc.
- exercise pole – 1 pc.
- gymnastic rings – 1 set
- log roll – 1 pc.
- push-up bar – 2 pcs.
- horizontal snake ladder – 1 pc.
- pull-up bar – 4 pcs.

Ask for an offer!
