Type 38, Male Double Lug Ø48,3

Add-on Four Socket Cross. Openable 4-way clamp to connect vertical posts to 4 horizontal tubes that are at right angles to each other. The vertical tube runs through the clamp.

Base flange for sloping sites, adjustable from 30° to 45°. As the fixing holes in the base cannot be fixed in line with the applied load, it is only intended for light loads or structures which are sufficiently supported by virtue of their design. Where a greater load is required, type 132 is normally used, with the upright tube bent to the required angle.

Angle Cross 0°- 45°. Connection clamp between the middle rail and the railing posts of sloping railings up to 45°.

Reducing Crossover 90°. Used as Type 28. reduction fitting makes it possible to design structures in two different tube diameters - horizontal Ø48.3 and vertical Ø42.4mm.

Reducing Short Tee. Used as Type 2. Rediction fitting makes it possible to design structures in two different tube diameters - horizontal Ø48.3 mm and vertical Ø42.4 mm.

Swivel Tee. Male spigot may be secured within another fitting for variable angles in hand railings for staircases, ramps and similar structures.
