Type 44, Single Swivel, Ø26,9 mm

Round tube D=26.9mm
wall thickness 2.35 mm
painted black with powder
maximum profile length 2 m

Railing Base Flange. Strong baseplate to support vertical post. Vertical wide rib with two setscrews increases the strength of the clamp. The fixing holes in the base flange should be in line with the applied load.

Four Socket Cross. 4-direction clamp used to fix uprights with 4 horizontal tubes that are perpendicular to each other. Upright tube passes through the clamp.

ATTENTION: The price is for one tube fitting. The figure shows a set of two fittings. Adjustable Swivel Tee. Always used in pairs to allow angle variation between 54 and 270 degrees. 608049B = 70° - 208° (min/max angle) 608049C = 71° - 217° (min/max angle) 608049D = 97° - 270° (min/max angle) 608049E = 54° - 215° (min/max angle)

Pin Hinge. Male hinge fitting, to be used in combination with type 62.

Groundsocket. A ground socket fitting inside the concrete for fixing upright tube. Post is retained with a locking setscrew, allowing easy insertion and removal (if necessary).
