Bicycle rack

DIMENSIONS
height: 84 cm
width: 6 cm
length: 116 cm
parking spaces: 2
weigth: 10 kg

MATERIALS
varnished steel

INSTALLATION
The bike rack is installed by setting anchoring pipes in the concrete

COLOR CHOICE: light grey, dark grey, black

By using bicycle racks, you offer the opportunity to store bicycles in an organized manner. The closed shape offers support and the ability to tie down the bike to prevent theft. The simple design makes these bike racks functional and durable.

Dimensions: 750*150*1070mm
Weight: 10 kg

Bicycle racks have:
• Standard base plate for installation
below the ground
• Height from the ground 900 mm
level
• Warranty 5 years

Material according to the series (different material choices in the series):
AROS 1
• Corten steel pipe 60x40x2 mm
or
• Galvanized steel pipe 60x40x2 mm

AROS 2
• Galvanized steel pipe ø 40x2 mm
or
• Stainless steel 316 pipe ø42x2 mm

BORG
• Corten steel 8 mm
or
• Galvanized steel 8 mm

STOR
• Corten steel 10 mm
or
• Galvanized steel 10 mm.

Maintenance:
Regular cleaning and oiling of the wood ensures that the pigment in the wood is preserved longer and the discoloration process is delayed.
• Annual cleaning and dirt removal with clean water.

NB! Do not use a pressure washer.

By using bicycle racks, you offer the opportunity to store bicycles in an organized manner. The closed shape offers support and the ability to tie down the bike to prevent theft. The simple design makes these bike racks functional and durable.

Dimensions: 1050*150*1070mm
Weight:9kg

Bicycle racks have:
• Standard base plate for installation
below the ground
• Height from the ground 900 mm
level
• Warranty 5 years

Material according to the series (different material choices in the series):
AROS 1
• Corten steel pipe 60x40x2 mm
or
• Galvanized steel pipe 60x40x2 mm

AROS 2
• Galvanized steel pipe ø 40x2 mm
or
• Stainless steel 316 pipe ø42x2 mm

BORG
• Corten steel 8 mm
or
• Galvanized steel 8 mm

STOR
• Corten steel 10 mm
or
• Galvanized steel 10 mm.

Maintenance:
Regular cleaning and oiling of the wood ensures that the pigment in the wood is preserved longer and the discoloration process is delayed.
• Annual cleaning and dirt removal with clean water.

NB! Do not use a pressure washer.

Bicycle rack - row arrangement
with rail system for screwing on,
lean-on hoop as round hoops (Ø 48 mm)
height: 800 mm
width: 460 mm
distance between bicycles: 700 mm
hot-dip galvanized

Mobile bike rack with advertising label

·for stable fixing of bicycles with rotating holding devices
with drive wheels
tire widths 6x up to 55 mm / 3x up to 45 mm
finish: galvanized, coated RAL 9005

Choice of 2 models:
- without sockets
- 3x socket IP54, 2x with dock for charging electric bikes.

CROSS SAVE bike racks are a series of products designed for customers who have limited parking space. By maintaining smaller distances between bike stands, it is possible to park a larger number of bikes in a small area.
number of positions: 5
width of stand/hanger: 144cm
height: 42-51cm
depth: 54cm
position width: 6.5cm
distance between positions 33cm
tube cross section: 18mm
tube thickness: 2mm
stand profile: 30x30x1.5mm
material: galvanized steel, galvanized and painted steel, stainless steel
mounting method: to the ground
