Grill lamp 3xLED amber

LED REFLECT grill lights are directional warning lamps, being an additional equipment for special vehicles.

length: 10 cm
height: 6,5 cm
voltage: 10-30V
LED colour: amber
4 flash modes
Approval E20 R10, E9 R65
Easy assembly (using the included screws)

WARRANTY 60 MONTHS

20x 0.25W LED
108x90,5x33mm
12V

Dimensions: 129x16x27mm
Type: ES6
Power: max 13.7 W
12-24V
6xLED yellow
23 different flashing modes with memory function, synchronizable
ECE R65 (XA1), ECE R10-05 (EMC), SAE Class 1, CA Title 13

Dimensions: 72x72x28mm
Voltage: 12-24V
4x1W LED yellow
5 different flashing alternatives, synchronizable together with more similar head lamps
metal hood.
1.20m wire
ECE R65 Class1 (XA1), ECE R10 (05 xxxx)

120x33x25mm
12-24V
8xLEDs, amber beacon
clear glass
18 different flashing alternatives, several flashers can be synchronized together
IP67
E9

The OPTIBEAM FLEX LM6 warning light offers completely new possibilities in terms of installation location. The light, which can be installed on surfaces curved up to 120 degrees, can be installed, for example, on the support leg of a crane, on the corners of a vehicle, or on other surfaces where a light with a straight and rigid body could not be used before. The design is aerodynamic and takes into account today's demands in terms of functions and attachments, including interference protection CISPR CLASS 3 (no radio interference) and ECE R65 class 2 (allowed in traffic both day and night), as well as IP67 protection class against water and dust. In addition, the FLEX LM6 has dual memory with separate wiring to quickly switch between steady light and warning light modes.

- Dimensions: 126.8 x 30.2 x 10.7 mm
- Bends up to 120° to fit a curved mounting surface.
- made of Dow Silastic silicone
- aerodynamic: minimal wind resistance
- screw fastening with glue, screw covers
- white glass.
- 6 High-Power LEDs
- 20 flashing modes, double memory, synchronisable: up to 20 lights
- short circuit protection, weatherproof, vibration resistant.
- working temperature: -40° ... +65°C
- Certificates: ECE R65 Class 2, ECE 10, SAE J595 Cl.1, SAE J845 Cl.1, CISPR25 Cl.3, CA13
- Cable length: 300 mm
- Voltage: 12/24V
