Grill lamp Super Thin - ST3 (M54) - 3 led - blue

LED REFLECT grill lights are directional warning lamps, being an additional equipment for special vehicles.

length: 10 cm
height: 6,5 cm
voltage: 10-30V
LED colour: amber
4 flash modes
Approval E20 R10, E9 R65
Easy assembly (using the included screws)

WARRANTY 60 MONTHS

127.5x27.8x17.2mm
amber beacon, clear lens
11-30V
leds: 6 x 1W
5 different flashing alternatives, several flashers can be synchronized together
IP67
hole distance 120mm
12V/0.4A / 24V/0.22A
SAE / Title XIII / E6 R65 / e13

LW0043 has features such as:
1 warning flash, two level of intensity, day and night
4xLEDs 10 W
according to standards such as ECE R10, ECE R65.
voltage is 12 V/24 V

Size: 150x103x13mm
Voltage: 12-24V
24xLED, amber
Transparent lens
22flash patterns, synchronizable
IP67
SAE / Title XIII / ECE R65 Class2 (XA2) / ECE R10

voltage is 12V/24V
6x LEDs 120 W
3 warning flashes
wire: 200 mm
dimensions: 131x31x6mm
according to standards such as ECE R10, ECE R65

The OPTIBEAM FLEX LM6 warning light offers completely new possibilities in terms of installation location. The light, which can be installed on surfaces curved up to 120 degrees, can be installed, for example, on the support leg of a crane, on the corners of a vehicle, or on other surfaces where a light with a straight and rigid body could not be used before. The design is aerodynamic and takes into account today's demands in terms of functions and attachments, including interference protection CISPR CLASS 3 (no radio interference) and ECE R65 class 2 (allowed in traffic both day and night), as well as IP67 protection class against water and dust. In addition, the FLEX LM6 has dual memory with separate wiring to quickly switch between steady light and warning light modes.

- Dimensions: 126.8 x 30.2 x 10.7 mm
- Bends up to 120° to fit a curved mounting surface.
- made of Dow Silastic silicone
- aerodynamic: minimal wind resistance
- screw fastening with glue, screw covers
- white glass.
- 6 High-Power LEDs
- 20 flashing modes, double memory, synchronisable: up to 20 lights
- short circuit protection, weatherproof, vibration resistant.
- working temperature: -40° ... +65°C
- Certificates: ECE R65 Class 2, ECE 10, SAE J595 Cl.1, SAE J845 Cl.1, CISPR25 Cl.3, CA13
- Cable length: 300 mm
- Voltage: 12/24V
