Type 28V, Reducing Crossover 90° Ø48,3 / Ø42,4

Swivel Base Plate (Unisize). For fixing structures to wall or floor, usually used with Type 42.

Base flange for sloping sites, adjustable from 11° to 29°. As the fixing holes in the base cannot be fixed in line with the applied load, it is only intended for light loads or structures which are sufficiently supported by virtue of their design.

Galv. Variable Elbow 40° - 70°. Elbow coupling as end stop for the overhead rail with a variable angle of 40 ° - 70 °. Usually used for handrails on stairs.

Flange with toeboard adaptor. Extra-heavy footplate for attachment against a shovel edge. Usually used on roofs.

Wall Flange. This clamp is used on structures where positional fixing is required. Do not use as a base flange to support guard railings or similar systems.

Clamp-On Tee. Used for adding to and modifying an existing structure.
